NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1
Page 145
Call Pickup - Group C-7
Service Conditions (cont’d)
12. The allowable station number type for a member of CALL PICKUP GROUP or CALL PICKUP
EXPAND GROUP is the telephone number only.
13. When using the FCH card with:
a.) Stations in up to a maximum of four different nodes can be assigned to a CALL PICKUP
GROUP or a CALL PICKUP EXPAND GROUP.
b.) When a CALL PICKUP GROUP/CALL PICKUP EXPAND GROUP has stations that belong to
different nodes, and the multiple Call Pickup/Call Pickup Expand stations are ringing
simultaneously, if ringing stations belong to the same node, the user will pick up the call in
assigned order. However, if ringing stations belong to different nodes, the user cannot pick up the
call in assigned order or terminated order. The user will first pick up the call terminated to the
station belonging to the same node of the user’s station. See the figures below.
Node A Node B
No.3 No.4 No.5 No.1 No.2
CALL PICKUP GROUP
The number below the station is the assigned order.
Example:All the Stations No. 1 through No. 5 belong to the same CALL PICKUP GROUP. When Stations No.1, No. 3 and No. 5 are
ringing:
• If the user answers via Station No. 4, the user will pick up a call terminated to Station No. 5 first (this feature allows the user to
pick up from the next station in assigned order). The user will then pick up Station No. 3, if Station No. 3 is still ringing.
• If the user answers via Station No. 2, the user will pick up a call terminated to Station No. 1 first.
