Configure Frame Relay over Other Protocols 273
2 Configuration Related to Frame Relay Switching
Only some simple Frame Relay switching configurations are covered in this section.
For other configurations, refer to the Link Layer Protocol.
Configure the commands fr switch and fr switching in system view, and
perform other configurations in synchronous serial interface view.
Table 314 Configure the commands related to Frame Relay switching
In addition to Frame Relay switching connections between serial interfaces, the fr
switch command also supports the Frame Relay switching connections between
ISDN BRI, ISDN PRI and dialer interfaces.
3 BDR-related Configuration
■ Adopt legacy BDR
If legacy BDR is adopted to implement Frame Relay over ISDN, the user can
refer to Dial-up of this manual for all the configurations except for the link layer
protocol on the dialer or physical ISDN interface. The link layer protocol should
be configured through the
link-protocol fr command.
Perform the following configuration in physical ISDN or dialer interface view.
Table 315 Configure the link layer protocol of the interface
The two ends of a BDR call should work with the same link layer protocol.
For a physical interface (such as an ISDN BRI or PRI interface), both the D channel
and B channel are configured with Frame Relay.
Configure the synchronous serial
interface with Frame Relay
link-protocol fr [ ietf | nonstandard
]
Set the Frame Relay interface type fr interface-type { dte | dce | nni }
Add a static address map fr map { ip | ipx } protocol-address
dlci dlci [ broadcast ] [ nonstandard
| ietf ] [ logic-channel
channel_number ] [ nocompress |
compression vj ] [ compression frf9 ]
Assign a DLCI number for the main
interface or a sub-interface
fr dlci dlci-number
Operation Command
Enable Frame Relay to implement PVC
switching
fr switching
Configure a terminal type for a Frame
Relay interface
fr interface-type { dte | dce | nni }
Assign DLCI number for the main interface
or a sub-interface
fr dlci dlci-number
Configure a Frame Relay switched virtual
circuit (SVC)
fr switch name interface type number
dlci dlci interface type number dlci
dlci
Operation Command
Configure the link layer protocol of the
interface to Frame Relay
link-protocol fr [ ietf |
nonstandard ]
