Packet Field IP Parameters
IP Destination IP Dest (low) and IP Dest (high)
IP Source IP Source (low) and IP Source (high)
Default: Ignore
Don’t Match
Applies the filtering action (drop/accept/log) if the contents of the packet field do
not fall within the range established by the matching set of (low) and (high) filter
parameters.
Ignore
Applies no filtering action if the contents of the packet field falls within the range
established by the matching set of (low) and (high) filter parameters.
Match
Applies the filtering action (drop/accept/log) if the contents of the packet field falls
within the range established by the matching set of (low) and (high) filter
parameters.
Encapsulation Type
Used with the Adjacent Host type of static route. Assigns one of three encapsulation
types.
Default: Ethernet
Ethernet
Standard Ethernet 2.0 encapsulation for hosts that support Ethernet. (Required for
point-to-point network interface or any type of X.25 interface.) If you are defining a
LAN interface (Ethernet or IEEE 802.x), you must specify the encapsulation method
supported by the attached network.
802.2
Select this option for hosts supporting 802.2 over 802.3 LAN interfaces. The 802.2
structure is encapsulated as shown, and is further encapsulated within a medium-
specific 802.x packet.
SNAP
Assigns an extension of 802.2 encapsulation for hosts supporting SNAP. The SNAP
structure is encapsulated within a medium-specific 802.x packet.
Export Action
Used in export route filters to control the flow of routing information between
protocols.
Default: PROPAGATE
IGNORE
Suppresses route advertising.
PROPAGATE
Advertises the route.
Internet Protocol
(IP) Parameters
7
Internet Protocol (IP) Parameters
Parameters and Options
7-11
