Accessing the Internet
Management Information Base
Internet Request for Comments 1156 defines the variable set required
for monitoring and controlling various components of the IP Internet.
The router’s MIB implementation is fully compliant with all
requirements of RFC 1156. Some of the NCL commands work in
conjunction with the Simple Network Management Protocol (SNMP)
agent and the IP routing application to provide access to the Internet
standard MIB. Use these commands to examine the MIB of any local or
remote network node that provides a standard SNMP/MIB
implementation.
The commands available in this category are the following.
Command Function
Rgeta Display the MIB IP address translation table (page 16-41).
Rgeti Display the MIB IP address table (page 16-42).
Rgetms Display the value of a branch of Internet standard MIB variables. (page 16-43).
Rgetr Display the MIB IP routing table. (page 16-45).
Rgets Display the value of an individual Internet standard MIB variable. (page 16-47).
These commands are described below. They display their output on the
console screen. To output the display to a printer or file instead of the
console screen, place the command syntax, as shown below for each
command, within the Print command (described on page 16-19).
Using the Network Control Language
Accessing the Internet Management Information Base
16-40
