Categories on the DoD IP Router Statistics screen are the following:
NAME Lists each network interface address in dotted decimal
notation.
Receive Lists the number of IP datagrams received by the network
interface.
Transmit Lists the number of IP datagrams transmitted by the
network interface.
Deliver Lists the number of IP datagrams addressed to the IP
router and delivered by the router to one of three
upper-layer protocols for processing. The three protocols
are ICMP (Internet Control Message Protocol), TCP
(Transmission Control Protocol), and UDP (User
Datagram Protocol). To see the counts of received and
transmitted ICMP datagrams detailed by message type,
you can use NCL’s Get command.
Dropped Lists the number of IP datagrams dropped by the network
interface. Dropped datagrams include (but are not limited
to) datagrams with faulty checksums and datagrams
requiring absent protocols. The interface also drops
datagrams as directed by source-address filters and
destination-address filters that were established during
the configuration process.
TOTAL Lists the total for each of the above counts for all IP
network interfaces.
