Options
Leave this field blank if you do not want to filter AppleTalk source networks.
Enter the AppleTalk network number in this field and leave the Source Net (high)
field blank if you are filtering a single AppleTalk source network.
Enter the lowest AppleTalk network number in this field and enter the highest
network number in the Source Net (high) field if you are filtering a range of
AppleTalk source networks.
Enter the Network list name in this field and leave the Source Net (high) field
blank if you want to use a Network list to establish the upper and lower range of
source network numbers.
For additional information, refer to “Source Net (high)” earlier in this chapter. For
more information about Network lists, refer to “Network Number (high)” and
“Network Number (low)” later in this chapter.
Source Node (high)
Sets the upper boundary of the range for filtering a datagram based on the contents
of its source node field.
Options
Leave this field blank if you do not want to filter AppleTalk source nodes.
Leave this field blank and enter the AppleTalk node identifier in the Source Node
(low) field if you are filtering a single AppleTalk source node.
Enter the highest AppleTalk node identifier in the range if you are filtering a range
of AppleTalk source nodes.
Leave this field blank and enter the name of the Node list in the Source Node
(low) field if you want to use a Node list to establish the upper and lower range of
AppleTalk source node identifiers.
For additional information, refer to “Source Node (low)” later in this chapter. For
more information about Node lists, refer to “Node (high)” and “Node (low)” earlier
in this chapter.
Source Node (low)
Sets the lower boundary of the range for filtering a datagram based on the contents
of its source node field.
Options
Leave this field blank if you do not want to filter AppleTalk source nodes.
Enter the AppleTalk node identifier in this field and leave the Source Node (high)
field blank if you are filtering a single AppleTalk source node.
Enter the lowest AppleTalk node identifier in this field and enter the highest node
identifier in the Source Node (high) field if you are filtering a range of AppleTalk
source nodes.
