Unsupported IE value
XXX
found
Meaning: For the indicated frame relay circuit, a valid status update or full status
message was received with an unrecognized or unsupported
Information Element (IE). XXX identifies Information Element
identifier code in question.
Unsupported NLPID found
XXX
Meaning: For the indicated frame relay circuit, a received data packet that
included a NLPID value that was not recognized. The NLPID identifies
the encapsulated data type. Packets received with unknown NLPIDs are
discarded. XXX identifies the NLPID value received.
V.25 bis to IP dup next hop, IP
X.X.X.X
Meaning: A duplicate IP next-hop entry has been configured in the IP to V.25 bis
mapping configuration. X.X.X.X is the IP address of the duplicate.
Action: Remove the duplicate entry. (If not removed, the first entry is used and
the second entry will be ignored.)
V35 circuit record missing
Meaning: A circuit has not been configured.
Action: Modify the configuration to ensure that it includes circuit records for
cct.
Wrong sequence number on MI enquiry
Meaning: For the indicated frame relay circuit, the other side of the frame relay
interface is issuing status enquiry messages with keep-alive sequence
numbers that are not as expected. That is, this sequence number is
more than one greater than the last one we received.
Event Log
Messages
17
Event Log Messages
cct: Circuit Event Messages
17-57
