Each frame relay MIB item can be accessed through the Network
Command Language (NCL) from the console screen. Use the NCL list
command to display all or a portion of the frame relay information base.
Use the NCL get command to obtain the value of any variable within the
information base. There are two methods of access, one using the names
of the branches and the other using the numbers.
exmib.fr table name.table entry
where:
table name
is the name of the fr table, and
table entry
is the actual value of the table entry.
Or, using the second method of access:
36.26.1.1.5.8
where:
8 is the frame relay circuit number (which is
system-assigned), and
5 is the MIB variable.
Data Link Connection Management Interface Table (dlctble)
The frame relay MIB variables, in alphabetical order, for the Data Link
Connection Management Interface Table are as follows:
active States which data link connection management scheme is
active and, by implication, which DLCI it uses, on the frame relay
interface. There are four possible values:
Disabled (1) indicates that there is no interface management
running on this interface.
LmiRev1 (2) is the original Local Management Interface (LMI).
ansiT1-617-D (3) indicates the use of ANSI Annex D of ANSI
T1-617.
ansiT1-617-B (4) indicates the use of ANSI Annex D of ANSI
T1-617 (not supported by HP).
Access methods:
Management Information Base Variables
cct: Circuits Information Base
18-24
