Enter the lowest AppleTalk socket number in this field and enter the highest
socket number in the Dest Sock (high) field if you are filtering a range of
AppleTalk destination sockets.
Enter the Socket list name in this field and leave the Dest Sock (high) field blank
if you want to use a Socket list to establish the upper and lower range of
destination socket numbers.
For additional information, refer to “Dest Sock (high)” earlier in this chapter. For
more information about Socket lists, refer to “Socket (high)” and “Socket (low)”
later in this chapter.
Effect
Determines whether datagrams are dropped or relayed (filtered) based on the
contents of a datagram field and a range established by a matching set of (low) and
(high) filter parameters. The datagram field and corresponding of (low) and (high)
filter parameters are listed in the following table:
Datagram Field AppleTalk Router Parameter
DDP type DDP Type (low) and DDP Type (high)
destination node Dest Node (low) and Dest Node (high)
destination socket Dest Sock (low) and Dest Sock (high)
destination network Dest Net (low) and Dest Net (high)
source network Source Net (low) and Source Net (high)
source node Source Node (low) and Source Node (high)
source socket Source Sock (low) and Source Sock (high)
Default: Ignore
Don’t Match
Applies the filtering action (drop/accept/log) if the contents of the datagram field do
not fall within the range established by the matching (low) and (high) filter
parameters.
Ignore
Applies no filtering action if the contents of the datagram field falls within the range
established by the matching (low) and (high) filter parameters.
Match
Applies the filtering action (drop/accept/log) if the contents of the datagram field
falls within the range established by the matching (low) and (high) filter parameters.
List Members
Displays a screen with options for creating a DDP Type list, Network list, Node list,
and Socket list. Each option on the screen displays a set of matching (low) and
(high) parameters for creating a list. The screen options and corresponding (low)
and (high) parameters are listed in the following table:
List Type Parameters
DDP Type DDP Type (low) and DDP Type (high)
Network Network (low) and Network (high)
Node Node (low) and Node (high)
Socket Socket (low) and Socket (high)
AppleTalk Parameters
Parameters and Options
12-10
