Module
Example:
get pm.slot2.state
state The current state of the port module. The following values are
possible.
0 = Dead
1 = Absent
2 = Hard Reset
3 = Soft Reset
4 = Selftest Pass
5 = Selftest Fail
6 = Downloading
7 = Booting
8 = Alive
9 = Running
hwid the type of port module in the slot. The following values are
possible.
0 = Empty Slot (i.e. No Card)
1 = Ethernet Port Module
2 = Synchronous WAN Port Module
3 = Token Ring Port Module
4 = FDDI Port Module
msg_tx the number of messages transmitted from the routing engine
to the port module.
msg_rx the number of messages received by the routing engine from
the port module.
msg_fail the number of message transmissions and receptions which
have failed.
trans_depth the maximum depth of the transactional message log.
Managment
Information Base
18
Management Information Base Variables
pm: Port Module Manager Information Base
18-87
