Options
Leave this field blank and enter the IPX packet type number in the Packet Type
(low) field if you are filtering a single IPX packet type number.
Enter the highest IPX packet type number in the range if you are filtering a range
of IPX packet type numbers.
Enter the list name in the Packet Type (low) field and leave this field blank if
you are creating an IPX Packet Type filter and want to create a range of packet
type numbers with a filter list.
For additional information, refer to “Packet Type (low)” later in this chapter.
Packet Type (low)
Sets the lower boundary of the range for filtering IPX packet type numbers when
creating a Packet Type filter or Packet Type list.
Options
Enter the IPX packet type number in this field and leave the Packet Type (high)
field blank if you are filtering a single IPX packet type number.
Enter the lowest IPX packet type number in this field and enter the highest
packet type number in the Packet Type (high) field if you are filtering a range of
IPX packet type numbers.
Enter the list name in this field and leave the Packet Type (high) field blank if
you are creating an IPX Packet Type filter and want to establish the range of
packet type numbers with a filter list.
For additional information, refer to “Packet Type (high)” earlier in this chapter.
Precedence
Assigns a priority value to the filter—the higher the precedence, the greater the
priority. You can construct up to 31 filters per interface. The Precedence value is
used when an in-coming packet meets several filter rules. In such an instance, the
filter rule with the highest priority (precedence) is applied to filter the packet.
Default: 1
Range: 1 to 31
Note: When two filters have equal precedence, the first configured filter takes
precedence over the second filter.
Random load
balancing
Provides two methods for managing IPX network traffic across circuits in a circuit
group: Random load balancing, Host ID load balancing.
Default: No
No
Enables Host ID load balancing—the router selects a circuit to carry all network
traffic (packets) between the source and destination systems.
IPX Protocol
Parameters
11
IPX Protocol Parameters
Parameters and Options
11-13
