Dest Node (low)
Sets the lower boundary of the range for filtering a datagram based on the contents
of its destination node field.
Options
Leave this field blank if you do not want to filter AppleTalk destination nodes.
Enter the AppleTalk node identifier in this field and leave the Dest Node (high)
field blank if you are filtering a single AppleTalk destination node.
Enter the lowest AppleTalk node identifier in this field and enter the highest node
identifier in the Dest Node (high) field if you are filtering a range of AppleTalk
destination nodes.
Enter the Node list name in this field and leave the Dest Node (high) field blank if
you want to use a Node list to establish the upper and lower range of destination
node identifiers.
For additional information, refer to “Dest Node (high)” earlier in this chapter. For
more information about Node lists, refer to “Node (high)” and “Node (low)” later in
this chapter.
Dest Sock (high)
Sets the upper boundary of the range for filtering a datagram based on the contents
of its destination socket field.
Options
Leave this field blank if you do not want to filter AppleTalk destination sockets.
Leave this field blank and enter the AppleTalk socket number in the Dest Sock
(low) field if you are filtering a single AppleTalk destination sockets.
Enter the highest AppleTalk socket number in the range if you are filtering a range
of AppleTalk destination sockets.
Leave this field blank and enter the name of the Socket list in the Dest Sock (low)
field if you want to use a Socket list to establish the upper and lower range of
AppleTalk destination socket numbers.
For additional information, refer to “Dest Sock (low)” later in this chapter. For more
information about Socket lists, refer to “Socket (high)” and “Socket (low)” later in
this chapter.
Dest Sock (low)
Sets the lower boundary of the range for filtering a datagram based on the contents
of its destination socket field.
Options
Leave this field blank if you do not want to filter AppleTalk destination sockets.
Enter the AppleTalk socket number in this field and leave the Dest Sock (high)
field blank if you are filtering a single AppleTalk destination socket.
