DEV CCT:
cct
- Not enough memory for compression
Meaning: Compression is configured on the circuit, but there is not enough free
memory to allocate the compression table.
Action: Either remove configured functionality that is unnecessary, or replace
the router with another one having more memory.
DEV CCT: cct - transmit congestion
Meaning: The router has dropped packets that were to be transmitted on this
circuit. The bit rate of traffic destined for this port is larger than the
media can handle. This could be due to either many circuits feeding this
one circuit too much data or the ring is too busy with other traffic to
allow all of the traffic the router would like to place on the ring.
Action: Investigate resegmenting your network to balance the flow of traffic
more evenly between segments.
The delay time is
X
minutes
Meaning: X minutes is the delay time request by the terminal adapter on the DLC
indication.
Disabled, LLC2 retries exhausted
Meaning: The circuit indicated in the object field of the event message has been
disabled because the router was unable to obtain positive
acknowledgment of an outstanding frame after a sequence of
retransmission attempts. The number of such attempts is governed by
the Retry Counter (N2), Retry Timer (T1), and Connect Retries LLC2
parameters.
Action: Verify point-to-point connectivity.
DLCI too large for interface;
XXX
Meaning: DLCI values exceeding that which could be fit into the length specified
during config uration. Primarily this will happen if there is no
management interface selected and PVCs are hand-configured with large
DLCIs. XXX identifies the DLCI which is too large.
Event Log Messages
cct: Circuit Event Messages
17-28
