total_log_error contains the aggregate count of token-ring adapter
log errors, the sum of the counts of log_ari_fci_err, log_burst_err,
log_dma_bus_err, log_dma_par_err, log_frm_cpy_err, log_line_err,
log_lost_frm, log_rx_congest, and log_token_err variables.
total_ring_error contains the aggregate count of ring errors, the
sum of the counts of ring_auto_rem, ring_cnt_overflow, ring_hard_err,
ring_lobe_wire, ring_one_station, ring_recover, ring_rem_station,
ring_sig_loss, ring_soft_err, and ring_tx_beacon variables.
total_rx_error contains the sum of the counts of log_rx_congest
and rx_suspended variables.
total_tx_error contains the sum of the counts of tx_frm_cmpi,
tx_frm_err, tx_frm_size_err, tx_ill_frm_fmt, tx_list_err, tx_odd_adr, and
tx_threshold variables.
tx_frm_cmpl (tint) contains the number of times the token-ring
adapter transmitted a frame and then generated an adapter-to-attached-
system interrupt. Such an interrupt is enabled or disabled by the frame
interrupt bit (bit 4 of
TRANSMIT_CSTAT). Because frames can be trans-
mitted faster than the adapter can cause the interrupts, each increment
of this counter can report the transmission of one or multiple frames.
tx_frm_err contains the number of times the token-ring adapter
recorded a transmit frame error. A transmit frame error occurs when
the token-ring adapter finds an erroneous start frame bit (bit 2 of
TRANSMIT_CSTAT). Either the bit is equal to 1 on a list that is not the
anticipated start of a frame, or the bit is equal to 0 on an anticipated
start of a frame.
tx_frm_size_err contains the number of times the token-ring
adapter recorded a transmit frame size error. A transmit frame size
error occurs when (1) the frame size count (bytes 7 and 8 of the transmit
parameter list) is not equal to the sum of the data count fields contained
in the parameter list, (2) when the frame size count is less than the
required header plus one byte of the I (Information) field date, or (3)
when the frame size count is equal to 0 (except in lists that define I
frames).
