HP (Hewlett-Packard) 200 Network Router User Manual



Managing Router Operations and
Resources
The commands available in this category are the following.
Command Function
[!]
[repetitions]
Repeat the last NCL command (page 16-4).
Atping
x.x [wait]
Send an AppleTalk Echo Protocol request to another AppleTalk node (page 16-4).
Boot Reboot the router (page 16-5).
Browse Display the entire current configuration, in Configuration Editor format (page 16-6).
Config Display the entire current configuration, in machine-readable format (page 16-6).
Crash Display the router’s shutdown history (page 16-7).
Date
[mm/dd/yy] [hh:mm:ss]
Set or display the router’s current date and time (page 16-7).
Disable
identifier
Disable a protocol, service, slot, or other configuration entity (page 16-8).
Edit Invoke the Configuration Editor without leaving NCL (page 16-8).
Enable
identifier
Enable a protocol, service, slot, or other configuration entity (page 16-9).
Exit Leave NCL and return to the Main menu (page 16-10).
Help
[type]
Get help for NCL commands (page 16-10).
Log
[specifier]
Lists the following:(page 16-11):
The event log messages generated since the last boot.
Warning, Performance, and Major event log messages only.
All messages in the current event log. (Lists up to 1000 lines.)
Only messages that contain the specified text string.
Logi Invoke the automatically updating Event Log without leaving NCL (page 16-13).
page Disable and re-enable display-paging mode for the console (page 16-14).
Password Assign, change, or remove password protection on the router (page 16-15).
Ping
X.X.X.X [count] [wait]
Send an Internet Control Message Protocol echo request to another node
(page 16-18).
Print
output command [type]
Direct NCL display command output to a printer or file (page 16-19).
Quick Invoke Quick Configuration without leaving NCL (page 16-20).
Rboot
X.X.X.X
[community]
Reboot the remote router at the indicated IP address (page 16-21)
Using the Network Control Language
Managing Router Operations and Resources
16-2
