Rgetda: Displaying the DECnet Router Level 2
Routing Table
Use NCL’s Rgetda command to format and display the DECnet router
level 2 (inter-area) routing table for a local or remote HP router.
Syntax
rgetda [X.X.X.X] [community]
[X.X.X.X] (optional) is the IP address of the local or remote
router in dotted decimal notation. If you omit this field, an IP
address on the local router will be used.
[community] (optional) is the name of the SNMP community
that grants access to that node. If you omit the name, public is
used. If you include a name, the address must also be included.
Example
rgetda 15.2.1.94
Displays the DECnet router inter-area routing table for the node
whose IP address is 15.2.1.94:
Area routes for 1.1
Dst Cst Hop Next
Hop
IF
1000.00
10 15 3 2.2 3
7711.52
60 6 2 3.1 4
The fields in the table are as follows:
Dst lists the destination DEC net area.
Cst contains the circuit cost to Dst.
Hop lists the number of router hops to Dst.
Next Hop lists the DEC net area and node number of the next hop
router.
IF lists the number the router assigned to the network interface for
Next Hop.
