Non-Broadcast Multi-
Access
Supports multiple (more than two) routers, but does not provide the ability to
address a single physical message to all routers. An example is a public switched
packet network.
Internet Address
Accepts the IP (Internet Protocol) address of the remote router port for the
destination network. Enter the address in dotted-decimal notation.
IP Address
Identifies the Internet Protocol address for an interface in dotted-decimal notation.
IP Address (high)
Sets the upper boundary of the IP address range when creating an IP address list.
Options
Leave this field blank and enter the IP address in the IP Address (low) field if you
are filtering a single IP address.
Enter the highest IP address in the range if you are filtering a range of IP
addresses.
For more information, refer to “IP Address (low)”. To learn how to apply a IP
Address list to a filter, refer to “IP Dest (low)” and “IP Source (low).”
IP Address (low)
Sets the lower boundary of the IP address range when creating an IP Address list.
Options
Enter the IP address in this field and leave the IP Address (high) field blank if you
are filtering a single IP address.
Enter the lowest IP address in this field and enter the highest IP address in the IP
Address (high) field if you are filtering a range of IP addresses,
For more information, refer to “IP Address (high)” earlier in this chapter. To learn
how to apply a IP Address list to a filter, refer to “IP Dest (low)” and “IP Source
(low).”
IP Dest (high)
Sets the upper boundary of the range for filtering a packet based on the contents of
its IP destination field.
Options
Leave this field blank if you do not want to filter an IP packet based on the
contents of its IP destination field.
Leave this field blank and enter the IP destination address in the IP Dest (low)
field if you are filtering a single IP destination address.
Enter the highest IP destination address in this field if you are filtering a range of
IP destination addresses.
Leave this field blank and enter the name of a IP Address list in the IP Dest (low)
field if you are establishing a range of IP destination addresses with a filter list.
Internet Protocol
(IP) Parameters
7
Internet Protocol (IP) Parameters
Parameters and Options
7-15
