log_dma_bus_err contains the number of direct-memory-access bus
errors that do not exceed the abort threshold.
log_dma_par_err contains the number of direct-memory-access
parity errors that do not exceed the abort threshold.
log_frm_cpy_err contains the number of times the token-ring adapt-
er (while in the receive/repeat mode) recognized a frame addressed to its
specific address but found the address-recognized-indicator bits not equal
to zero. This indicates a possible line hit or duplicate address.
log_line_err contains the number of times the token-ring adapter
(while in the receive/repeat mode) recognized a line error. A line error
is recorded when (1) a code violation exists between the starting and
ending delimiters of a frame, (2) a code violation exists in a token, or
(3) a frame check sequence error exists.
log_lost_frm contains the number of times the token-ring adapter
(while in the transmit/stripping mode) failed to receive the end of a
frame that it had previously transmitted.
log_rx_congest contains the number of times the token-ring adapter
(while in the repeat mode) recognized a frame addressed to its specific
address.
log_token_err contains the number of times a token-ring adapter in
an active monitoring station detected an error with the token protocol.
The errors may be the following:
A token with a nonzero priority has the monitor count bit equal to
one, indicating a circulating high-priority token.
A frame has the monitor count bit equal to one, indicating a circulat-
ing frame.
No token or frame is received within a 10-millisecond window.
The starting delimiter/token sequence has a code violation in an area
where code violations must not occur.
octets_rx_per_sec contains the number of octets that this circuit has
received in the last second.
