Socket (high)
Sets the upper boundary of the range for filtering AppleTalk source or destination
sockets when creating a Socket list.
Options
Leave this field blank and enter the AppleTalk socket number in the Socket (low)
field if you are filtering a single AppleTalk source or destination socket.
Enter the highest AppleTalk socket number in the range if you are filtering a range
of AppleTalk source or destination sockets.
For additional information, refer to “Socket (low)” later in this chapter. To learn how
to assign a Socket list to a filter, refer to “Dest Sock (low)” and “Source Sock (low).”
Socket (low)
Sets the lower boundary of the range for filtering AppleTalk source or destination
sockets when creating a Socket list.
Options
Enter the AppleTalk socket number in this field and leave the Socket (high) field
blank if you are filtering a single AppleTalk source or destination socket.
Enter the lowest AppleTalk socket number in this field and enter the highest
socket number in the Socket (high) field if you are filtering a range of AppleTalk
source or destination sockets.
For additional information, refer to “Socket (high)” earlier in this chapter. To learn
how to assign a Socket list to a filter, refer to “Dest Sock (low)” and “Source Sock
(low).”
Source Net (high)
Sets the upper boundary of the range for filtering a datagram based on the contents
of its source network field.
Options
Leave this field blank if you do not want to filter AppleTalk source networks.
Leave this field blank and enter the AppleTalk network number in the Source Net
(low) field if you are filtering a single AppleTalk source network.
Enter the highest AppleTalk network number in the range if you are filtering a
range of AppleTalk source networks.
Leave this field blank and enter the name of the Network list in the Source Net
(low) field if you want to use a Network list to establish the upper and lower
range of AppleTalk destination network numbers.
For additional information, refer to “Source Net (low)” later in this chapter. For
more information about Network lists, refer to “Network Number (high)” and
“Network Number (low)” later in this chapter.
Source Net (low)
Sets the lower boundary of the range for filtering a datagram based on the contents
of its source network field.
