tx_congestion Contains the number of times where a buffer wasn’t
available to transmit a frame.
upstream_mac Contains the 48-bit address of the FDDI upstream
neighbor.
Frame Relay Management Information Base
The Frame Relay MIB tables are organized under the experimental MIB
(“exmib”--number 26) in a six-level tree (instead of under the cct MIB).
exmib Information base identifier
fr Frame Relay managed object
table variable dlctble or errtbl listed below
entry Fixed entry
data variable Data type
[cct #] Circuit number
table variable ccttbl listed below
entry Fixed entry
data variable Data type
[cct #] Circuit number
ddd dlci
The table variables are:
Data Link Connection Management Interface Table (dlctble)
Error Table (errtbl)
Circuit Table (ccttbl)
Each circuit number ([cct #]) corresponds to the number assigned to
that circuit in the ‘‘Circuit Name’’ listing in the first level of the ‘‘Circuits’’
menu in the main screen of the Configuration Editor.
Figure 18- shows this organization.
The Management Information Base for Frame Relay contains the values
for these tables, which are described in the following sections.
