Signal Descriptions
A-24 Copyright © 2003-2007 ARM Limited. All rights reserved. ARM DUI 0224F
SSPFSSIN YU129 80 79 YU50 HRESPS0
SSPRXD YU130 82 81 YU49 HREADYS
SSPCLKOUT YU131 84 83 YU48 HMASTLOCKS
SSPFSSOUT YU132 86 85 YU47 HSELS
SSPTXD YU133 88 87 YU46 HBURSTS2
nSSPCTLOE YU134 90 89 YU45 HBURSTS1
nSSPOE YU135 92 91 YU44 HBURSTS0
LT_CLCD_SPARE0 YU136 94 93 YU43 HPROTS3
LT_CLCD_SPARE1 YU137 96 95 YU42 HPROTS2
LT_CLCD_SPARE2 YU138 98 97 YU41 HPROTS1
LT_CLCD_SPARE3 YU139 100 99 YU40 HPROTS0
NC YU140 102 101 YU39 HSIZES1
LCDMODE0 YU141 104 103 YU38 HSIZES0
LCDMODE1 YU142 106 105 YU37 HTRANSS1
NC YU143 108 107 YU36 HTRANSS0
LTHBUSREQ YU144 110 109 YU35 NC
LTHGRANT YU145 112 111 YU34 NC
LTHLOCK YU146 114 113 YU33 NC
NC YU147 116 115 YU32 NC
HDATAS0 YU148 118 117 YU31 NC
HDATAS1 YU149 120 119 YU30 NC
HDATAS2 YU150 122 121 YU29 NC
HDATAS3 YU151 124 123 YU28 LT_CLAC
HDATAS4 YU152 126 125 YU27 LT_CLFP
Table A-11 HDRY (J12) signals (continued)
Platform signal Tile signal Pin Pin
Tile
signal
Platform signal
