ASYNCHRONOUS SERIAL I/O UNIT
11.3 REGISTER DEFINITIONS
Table 11-5 lists the registers associated with the SIO unit and the following sections contain bit
descriptions for each register.
Table 11-5. SIO Registers (Sheet 1 of 2)
Register
Expanded
Address
PC/AT*
Address
Function
PINCFG
(read/write)
0F826H Pin Configuration:
Connects the SIO1 transmit data (TXD1), data terminal ready
(DTR1#), and request to send (RTS1#) signals to package pins.
P1CFG
(read/write)
0F820H Port 1 Configuration:
Connects the SIO0 ring indicator (RI0#), data set ready (DSR0#),
data terminal ready (DTR0#), request to send (RTS0#), and data
carrier detected (DCD0#) signals to package pins.
P2CFG
(read/write)
0F822H Port 2 Configuration:
Connects the SIO0 clear to send (CTS0#), transmit data (TXD0),
and receive data (RXD0) signals to package pins.
P3CFG
(read/write)
0F824H Port 3 Configuration:
Connects COMCLK to the package pin.
SIOCFG
(read/write)
0F836H SIO and SSIO Configuration:
Connects the SIO
n
modem input signals internally or to package
pins and connects either the internal SERCLK signal or the
COMCLK pin to the SIO
n
baud-rate generator input.
DLL0
DLL1
(read/write)
0F4F8H
0F8F8H
03F8H
02F8H
Divisor Latch Low:
Stores the lower 8 bits of the SIO
n
baud-rate generator divisor.
DLH0
DLH1
(read/write)
0F4F9H
0F8F9H
03F9H
02F9H
Divisor Latch High:
Stores the upper 8 bits of the SIO
n
baud-rate generator divisor.
TBR0
TBR1
(write only)
0F4F8H
0F8F8H
03F8H
02F8H
Transmit Buffer:
Holds the data byte to transmit.
RBR0
RBR1
(read only)
0F4F8H
0F8F8H
03F8H
02F8H
Receiver Buffer:
Holds the data byte received.
LCR0
LCR1
(read/write)
0F4FBH
0F8FBH
03FBH
02FBH
Line Control:
Specifies the data frame (word length, number of stop bits, and
type of parity) for transmissions and receptions. Allows the
transmitter to transmit a break condition.
LSR0
LSR1
(read only)
0F4FDH
0F8FDH
03FDH
02FDH
Line Status:
Contains the transmitter empty, transmit buffer empty, receive
buffer full, and receive error flags.
IER0
IER1
(read/write)
0F4F9H
0F8F9H
03F9H
02F9H
Interrupt Enable:
Independently connects the four signals (modem status, receive
line status, transmit buffer empty, and receive buffer full) to the
interrupt request output (SIOINT
n
).
