CHAPTER 8 FIXING SYSTEM
8-10
COPYRIGHT
©
2000 CANON INC. CANON imageRUNNER 600 REV.1 JAN. 2000 PRINTED IN U.S.A.
E. Controlling the Thermistor Reciprocating Mechanism
Part 2>Chapter 7>5.3
Figure 8-205 shows the control system used to control the reciprocating mechanism of the
thermistor.
Figure 8-205 Construction of the Control System
Main thermistor
Cam
One-way clutch
Cleaning belt drive belt solenoid (SL2)
(front)
(rear)
Upper fixing roller
Reciprocating width: 12 mm
