CHAPTER 13 TROUBLESHOOTING
Code
E5F7
E5F6
ItemDetail code
01
02
05
Description
• The saddle tray home position sensor does not turn on
when the saddle tray motor has been driven for 8
seconds or longer.
• The saddle tray home position sensor does not turn off
when the saddle tray motor has been driven for 1
second or longer.
• The paper pressure top position sensor does not turn on
when the paper pressure plate motor has been driven
for 0.3 second or longer after the paper pressure plate
home position sensor turned off.
E5F8
01
• Saddle tray motor
(M20)
• Saddle tray home
position sensor
(PI49)
• Paper pressure
plate motor
(M38)
• Paper pressure
plate top position
sensor (PI75)
• Guide home
position sensor
(PI73) connector
• Paper pressure
plate home
position sensor
(PI74) connector
• The state of guide home position sensor connector
disconnection is detected.
02
• The state of paper pressure plate home position sensor
connector disconnection is detected.
• Paper pressure
plate top position
sensor (PI75)
connector
03
• The state of paper pressure plate top position sensor
connector disconnection is detected.
• Paper pressure
plate motor
(M38)
• Paper pressure
plate top position
sensor (PI75)
03
• The paper pressure top position sensor does not turn
off when the paper pressure plate motor has been
driven for 0.3 second or longer during movement from
the paper pressure plate top position to the home
position.
• Paper pressure
plate motor
(M38)
• Paper pressure
plate motor clock
sensor (PI61)
04
• The count of pulses detected by the paper pressure
plate motor clock sensor has fallen to a predetermined
level or lower.
3. Folder
Code
E518
Item
• Folder motor (M14)
Detection
• Clock input from the folding motor has fallen to a
predetermined level or lower during folder motor
rotation.
