CHAPTER 13 TROUBLESHOOTING
13-192
COPYRIGHT
©
1999 CANON INC. CANON imageRUNNER 600 REV.1 JAN. 2000 PRINTED IN U.S.A.
Remarks
0: ON
0: ON
0: ON
0: ON
0: ON
0: ON
0: ON
1: closed
1: ON
1: ON
1: ON
1: ON
1: ON
0: ON
0: ON
0: ON
Description
7-segment LED0
7-segment LED1
7-segment LED2
7-segment LED3
7-segment LED4
7-segment LED5
7-segment LED6
ADF open/closed sensor
Slide switch 0
Slide switch 1
Slide switch 2
Slide switch 3
Slide switch 4
Push switch 1
Push switch 2
Push switch 3
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Not used
Signal
7SEG_D
7SEG_E
7SEG_C
7SEG_G
7SEG_B
7SEG_F
7SEG_A
RFOP
SSW-0
SSW-1
SSW-2
SSW-3
SSW-4
PSHSW-1
PSHSW-2
PSHSW-3
Connector
CPU
CPU
CPU
CPU
CPU
CPU
CPU
J12-15
J51-5
J51-4
J51-3
J51-2
J51-6
CPU
CPU
CPU
bit
bit0
bit1
bit2
bit3
bit4
bit5
bit6
bit7
bit0
bit1
bit2
bit3
bit4
bit5
bit6
bit7
bit0
bit1
bit2
bit3
bit4
bit5
bit6
bit7
I/O>FEEDER
Address
P010
P011
P012
