82575EB Gigabit Ethernet Controller — Hardware Accessed Words
Intel
®
82575EB Gigabit Ethernet Controller 324632-003
Software Developer’s Manual and EEPROM Guide Revision: 2.1
78 January 2011
4.5.1.29.6 Configuration Customization Options PCI Function 1 (Word 35h)
This word is the same as word 31h, but for function 1 of the device.
4.5.1.29.7 iSCSI Option ROM Version (Word 36h)
Word 0x36 of the NVM is used to store the version of iSCSI Option ROM updated as the same format as
PXE Version at Word 0x32. The value must be above 0x2000 and the value below (word 0x1FFF = 16
KB NVM size) is reserved. iSCSIUtl, FLAUtil, DMiX update iSCSI Option ROM version if the value is
above 0x2000, 0x0000, or 0xFFFF. The value (0x0040 - 0x1FFF) should be kept and not be overwritten.
4.5.1.29.8 Alternate MAC Address Pointer (Word 37h)
This word may point to a location in the EEPROM containing additional MAC addresses used by system
management functions. If the additional MAC addresses are not supported, the word shall be set to
0xFFFF
4.5.1.29.9 Setup Options PCI Function 2 (Word 38h)
This word is the same as word 30h, but for function 2 of the device.
4.5.1.29.10 Configuration Customization Options PCI Function 2 (Word 39h)
This word is the same as word 31h, but for function 2 of the device.
4.5.1.29.11 Setup Options PCI Function 3 (Word 3Ah)
This word is the same as word 30h, but for function 3 of the device.
4.5.1.29.12 Configuration Customization Options PCI Function 3 (Word 3Bh)
This word is the same as word 31h, but for function 3 of the device.
4.5.1.29.13 iSCSI Boot Configuration Offset (Word 3Dh)
4.5.1.29.13.1 iSCSI Module Structure
Bit Name Description
15:0 Offset Defines the offset in EEPROM where the iSCSI boot configuration structure starts.
Configuration Item Size in Bytes Comments
iSCSI Boot Signature 2 ‘i’, ‘S’
iSCSI Block Size 2 Total byte size of the iSCSI configuration block
Structure Version 1 Version of this structure. Should be set to 1.
Reserved 1 Reserved for future use.
Initiator Name 255 + 1 iSCSI initiator name. This field is optional and built by manual input, DHCP host
name, or with MAC address as defined in section 4.4.
