Appendix
Rev. 4.00 Sep. 14, 2005 Page 969 of 982
REJ09B0023-0400
Reset State Power Down Mode
Type Pin Name Power-On Manual
Software
Standby Sleep
Bus-
Released
Reset
SCIF[2:0] RxD[2:0] Z+ I+ Z+ I+ I+
TxD[2:0] Z+ O/Z+ O/Z+*
4
O/Z+ O/Z+
SCK[2:0] Z+ I+/O K/Z+*
4
I+/O I+/O
RTS[2:0] Z+ I+/O K/Z+*
4
I+/O I+/O
CTS[2:0] Z+ I+/O K/Z+*
4
I+/O I+/O
AUD AUDSYNC Z+ O O O O
AUDCK O O O O O
AUDATA[3:0] Z+ O O O O
H-UDI*
8
ASEBRKAK O O O O O
ASEMD0 I I*
5
I*
5
I*
5
I*
5
TCK I++ I++ I++ I++ I++
TDI I++ I++ I++ I++ I++
TMS I++ I++ I++ I++ I++
TRST I++ I++ I++ I++ I++
TDO O/Z*
7
O/Z*
7
O/Z*
7
O/Z*
7
O/Z*
7
USB TXDMNS
TXDPLS
Z+ O O/Z+*
4
O O
DMNS
DPLS
VBUS
Z+ I+ I+ I+ I+
SUSPND
TXENL
Z+ O O/Z+*
4
O O
XVDATA
UCLK
Z+ I+ I+ I+ I+
DP
DM
Z I/O I I/O I/O
A/D AN[7:0] Z I Z I I
IIC2 SCL
SDA
Z I/O Z I/O I/O
