Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 873 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Bit rate register_1 SCBRR_1 8 H'A441 0004 SCIF 8
Serial control register_1 SCSCR_1 16 H'A441 0008 16
Transmit FIFO data register_1 SCFTDR_1 8 H'A441 000C 8
Serial status register_1 SCFSR_1 16 H'A441 0010 16
Receive FIFO data register_1 SCFRDR_1 8 H'A441 0014 8
FIFO control register_1 SCFCR_1 16 H'A441 0018 16
FIFO data count register_1 SCFDR_1 16 H'A441 001C 16
Serial port register_1 SCSPTR_1 16 H'A441 0020 16
Line status register_1 SCLSR_1 16 H'A441 0024 16
Serial mode register_2 SCSMR_2 16 H'A442 0000 16
Bit rate register_2 SCBRR_2 8 H'A442 0004 8
Serial control register_2 SCSCR_2 16 H'A442 0008 16
Transmit FIFO data register_2 SCFTDR_2 8 H'A442 000C 8
Serial status register_2 SCFSR_2 16 H'A442 0010 16
Receive FIFO data register_2 SCFRDR_2 8 H'A442 0014 8
FIFO control register_2 SCFCR_2 16 H'A442 0018 16
FIFO data count register_2 SCFDR_2 16 H'A442 001C 16
Serial port register_2 SCSPTR_2 16 H'A442 0020 16
Line status register_2 SCLSR_2 16 H'A442 0024 16
— — — — — —
USB interrupt flag register 0 USBIFR0 8 H'A448 0000 USB 8
USB interrupt flag register 1 USBIFR1 8 H'A448 0001 8
USBEP0i data register USBEPDR0i 8 H'A448 0002 8
USBEP0o data register USBEPDR0o 8 H'A448 0003 8
USB trigger register USBTRG 8 H'A448 0004 8
USB FIFO clear register USBFCLR 8 H'A448 0005 8
USBEP0o receive data size register USBEPSZ0o 8 H'A448 0006 8
USBEP0s data register USBEPDR0s 8 H'A448 0007 8
USB data status register USBDASTS 8 H'A448 0008 8
USB interrupt select register 0 USBISR0 8 H'A448 000A 8
USB endpoint stall register USBEPSTL 8 H'A448 000B 8
USB interrupt enable register 0 USBIER0 8 H'A448 000C 8
