Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 78 of 982
REJ09B0023-0400
System Control Instructions
Table 2.24 System Control Instructions
Instruction
Instruction Code
Operation
Execution
States
T Bit
CLRMAC 0000000000101000 0 → MACH, MACL 1 —
CLRS 0000000001001000 0 → S 1 —
CLRT 0000000000001000 0 → T 1 0
LDC Rm,SR 0100mmmm00001110 Rm → SR 6 LSB
LDC Rm,GBR 0100mmmm00011110 Rm → GBR 4 —
LDC Rm,VBR 0100mmmm00101110 Rm → VBR 4 —
LDC Rm,SSR 0100mmmm00111110 Rm → SSR 4 —
LDC Rm,SPC 0100mmmm01001110 Rm → SPC 4 —
LDC Rm,R0_BANK 0100mmmm10001110 Rm → R0_BANK 4 —
LDC Rm,R1_BANK 0100mmmm10011110 Rm → R1_BANK 4 —
LDC Rm,R2_BANK 0100mmmm10101110 Rm → R2_BANK 4 —
LDC Rm,R3_BANK 0100mmmm10111110 Rm → R3_BANK 4 —
LDC Rm,R4_BANK 0100mmmm11001110 Rm → R4_BANK 4 —
LDC Rm,R5_BANK 0100mmmm11011110 Rm → R5_BANK 1 —
LDC Rm,R6_BANK 0100mmmm11101110 Rm → R6_BANK 4 —
LDC Rm,R7_BANK 0100mmmm11111110 Rm → R7_BANK 4 —
LDC.L @Rm+,SR 0100mmmm00000111 (Rm) → SR, Rm + 4 → Rm 8 LSB
LDC.L @Rm+,GBR 0100mmmm00010111 (Rm) → GBR, Rm + 4 → Rm 4 —
LDC.L @Rm+,VBR 0100mmmm00100111 (Rm) → VBR, Rm + 4 → Rm 4 —
LDC.L @Rm+,SSR 0100mmmm00110111 (Rm) → SSR, Rm + 4 → Rm 4 —
LDC.L @Rm+,SPC 0100mmmm01000111 (Rm) → SPC, Rm + 4 → Rm 4 —
LDC.L @Rm+,
R0_BANK
0100mmmm10000111 (Rm) → R0_BANK,
Rm + 4 → Rm
4 —
LDC.L @Rm+,
R1_BANK
0100mmmm10010111 (Rm) → R1_BANK,
Rm + 4 → Rm
4 —
LDC.L @Rm+,
R2_BANK
0100mmmm10100111 (Rm) → R2_BANK,
Rm + 4 → Rm
4 —
LDC.L @Rm+,
R3_BANK
0100mmmm10110111 (Rm) → R3_BANK,
Rm + 4 → Rm
4 —
