Section 12 Bus State Controller (BSC)
Rev. 4.00 Sep. 14, 2005 Page 340 of 982
REJ09B0023-0400
Table 12.8 Relationship between BSZ1, 0, A2/3ROW1, 0, and Address Multiplex Output
(1)-1
Setting
BSZ
1, 0
A2/3
ROW
1, 0
A2/3
COL
1, 0
11 (32 bits) 00 (11 bits) 00 (8 bits)
Output Pin of
This LSI
Row Address
Output Cycle
Column Address
Output Cycle
SDRAM Pin
Function
A17 A25 A17
A16 A24 A16
A15 A23 A15
Unused
A14 A22*
2
A22*
2
A12 (BA1)
A13 A21*
2
A21*
2
A11 (BA0)
Specifies bank
A12 A20*
2
L/H*
1
A10/AP Specifies
address/precharge
A11 A19 A11 A9
A10 A18 A10 A8
A9 A17 A9 A7
A8 A16 A8 A6
A7 A15 A7 A5
A6 A14 A6 A4
A5 A13 A5 A3
A4 A12 A4 A2
A3 A11 A3 A1
A2 A10 A2 A0
Address
A1 A9 A1
A0 A8 A0
Unused
Example of connected memory
64-Mbit product (512 kwords × 32 bits × 4 banks, column 8 bits product): 1
16-Mbit product (512 kwords × 16 bits × 2 banks, column 8 bits product): 2
Notes: 1. L/H is a bit used in the command specification; it is fixed at L or H according to the
access mode.
2. Bank address specification
