Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 900 of 982
REJ09B0023-0400
Register
Abbreviation Power-On Reset Manual Reset
Software
Standby Module Standby Sleep Module
CMCOR_0 Initialized Retained Retained Retained Retained CMT
CMSTR_1 Initialized Retained Retained Retained Retained
CMCSR_1 Initialized Retained Retained Retained Retained
CMCNT_1 Initialized Retained Retained Retained Retained
CMCOR_1 Initialized Retained Retained Retained Retained
TCR_3 Initialized Retained Initialized Initialized Retained MTU
TCR_4 Initialized Retained Initialized Initialized Retained
TMDR_3 Initialized Retained Initialized Initialized Retained
TMDR_4 Initialized Retained Initialized Initialized Retained
TIORH_3 Initialized Retained Initialized Initialized Retained
TIORL_3 Initialized Retained Initialized Initialized Retained
TIORH_4 Initialized Retained Initialized Initialized Retained
TIORL_4 Initialized Retained Initialized Initialized Retained
TIER_3 Initialized Retained Initialized Initialized Retained
TIER_4 Initialized Retained Initialized Initialized Retained
TOER Initialized Retained Initialized Initialized Retained
TOCR Initialized Retained Initialized Initialized Retained
TGCR Initialized Retained Initialized Initialized Retained
TCNT_3 Initialized Retained Initialized Initialized Retained
TCNT_4 Initialized Retained Initialized Initialized Retained
TCDR Initialized Retained Initialized Initialized Retained
TDDR Initialized Retained Initialized Initialized Retained
TGRA_3 Initialized Retained Initialized Initialized Retained
TGRB_3 Initialized Retained Initialized Initialized Retained
TGRA_4 Initialized Retained Initialized Initialized Retained
TGRB_4 Initialized Retained Initialized Initialized Retained
TCNTS Initialized Retained Initialized Initialized Retained
TCBR Initialized Retained Initialized Initialized Retained
TGRC_3 Initialized Retained Initialized Initialized Retained
