Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 899 of 982
REJ09B0023-0400
Register
Abbreviation Power-On Reset Manual Reset
Software
Standby Module Standby Sleep Module
DAR_1 Undefined Undefined Retained Retained Retained DMAC
DMATCR_1 Undefined Undefined Retained Retained Retained
CHCR_1 Initialized Initialized Retained Retained Retained
SAR_2 Undefined Undefined Retained Retained Retained
DAR_2 Undefined Undefined Retained Retained Retained
DMATCR_2 Undefined Undefined Retained Retained Retained
CHCR_2 Initialized Initialized Retained Retained Retained
SAR_3 Undefined Undefined Retained Retained Retained
DAR_3 Undefined Undefined Retained Retained Retained
DMATCR_3 Undefined Undefined Retained Retained Retained
CHCR_3 Initialized Initialized Retained Retained Retained
DMAOR Initialized Initialized Retained Retained Retained
DMARS0 Initialized Initialized Retained Retained Retained
DMARS1 Initialized Initialized Retained Retained Retained
SDIR Initialized*
4
Retained Retained Retained Retained H-UDI
SDIDH Initialized Retained Retained Retained Retained
SDIDL Initialized Retained Retained Retained Retained
ICCR1 Initialized Retained Retained Retained Retained IIC2
ICCR2 Initialized Retained Retained Retained Retained
ICMR Initialized Retained Retained Retained Retained
ICIER Initialized Retained Retained Retained Retained
ICSR Initialized Retained Retained Retained Retained
SAR Initialized Retained Retained Retained Retained
ICDRT Undefined Retained Retained Retained Retained
ICDRR Undefined Retained Retained Retained Retained
NF2CYC Initialized Retained Retained Retained Retained
CMSTR_0 Initialized Retained Retained Retained Retained CMT
CMCSR_0 Initialized Retained Retained Retained Retained
CMCNT_0 Initialized Retained Retained Retained Retained
