Section 22 Pin Function Controller (PFC)
Rev. 4.00 Sep. 14, 2005 Page 822 of 982
REJ09B0023-0400
Port Port Function (Related Module) Other Function (Related Module)
G PTG13 input/output (port)
PTG12 input/output (port)
PTG11 input/output (port)
PTG10 input/output (port) SDA input/output (IIC2)
PTG9 input/output (port) SDL input/output (IIC2)
PTG8 input/output (port)
PTG7 input (port) AN7 input (ADC)
PTG6 input (port) AN6 input (ADC)
PTG5 input (port) AN5 input (ADC)
PTG4 input (port) AN4 input (ADC)
PTG3 input (port) AN3 input (ADC)
PTG2 input (port) AN2 input (ADC)
PTG1 input (port) AN1 input (ADC)
PTG0 input (port) AN0 input (ADC)
H PTH14 input/output (port) RTS2 input/output (SCIF2)
PTH13 input/output (port) RXD2 input (SCIF2)
PTH12 input/output (port) TXD2 output (SCIF2)
PTH11 input/output (port) CTS2 input/output (SCIF2)
PTH10 input/output (port) SCK2 input/output (SCIF2)
PTH9 input/output (port) RTS1 input/output (SCIF1)
PTH8 input/output (port) RXD1 input (SCIF1)
PTH7 input/output (port) TXD1 output (SCIF1)
PTH6 input/output (port) CTS1 input/output (SCIF)
PTH5 input/output (port) SCK1 input/output (SCIF1)
PTH4 input/output (port) RTS0 input/output (SCIF0)
PTH3 input/output (port) RXD0 input (SCIF0)
PTH2 input/output (port) TXD0 output (SCIF0)
PTH1 input/output (port) CTS0 input/output (SCIF0)
PTH0 input/output (port) SCK0 input/output (SCIF0)
