Section 2 CPU
Rev. 4.00 Sep. 14, 2005 Page 28 of 982
REJ09B0023-0400
39
A0G
A1G
32 31
A0
A1
M0
M1
X0
X1
Y0
Y1
DSR
MS
ME
MOD
0
(c) DSP mode register configuration (DSP = 1)
Figure 2.2 Register Configuration in Each Processing Mode (2)
Register values after a reset are shown in table 2.1.
Table 2.1 Initial Register Values
Type Registers Initial Value*
General registers R0 to R15 Undefined
Control registers SR RB bit = 1, BL bit = 1, I3 to I0 = 1111 (H'F),
The reserved bits other than bit 30 are all 0;
bit 30 is 1, others undefined
GBR, SSR, SPC Undefined
VBR H'00000000
RS, RE Undefined
MOD Undefined
System registers MACH, MACL, PR Undefined
PC H'A0000000
DSP registers A0, A0G, A1, A1G, M0, M1,
X0, X1, Y0, Y1
Undefined
DSR H'00000000
Note: * Initialized by a power-on or manual reset.
