Rev. 4.00 Sep. 14, 2005 Page 5 of 982
REJ09B0023-0400
Items Specification
Advanced user
debugger (AUD)
• Six output pins
• Trace of branch source/destination address
• Window data trace function
• Full trace function
All trace data can be output by stalling the CPU even when the
trace data is not output in time
• Real-time trace function
Function to output trace data that can be output at the range not to
stall the CPU
Multi-function timer
pulse unit (MTU)
• Maximum 16-pulse input/output
• Selection of 8 counter input clocks for each channel
• The following operations can be set for each channel:
Waveform output at compare match
Input capture function
Counter clear operation
A maximum 12-phase PWM output is possible in combination with
synchronous operation
• Buffer operation settable for channels 0,3,and 4
• Phase counting mode settable independently for each of channels 1
and 2
• Cascade connection operation
• Fast access via internal 16-bit bus
• 23 interrupt sources
• Automatic transfer of register data
• A/D converter conversion start trigger can be generated
• Module standby mode can be set
