Section 25 Electrical Characteristics
Rev. 4.00 Sep. 14, 2005 Page 914 of 982
REJ09B0023-0400
Table 25.3 DC Characteristics (5) [USB Transceiver-Related Pins*]
Conditions: Ta = −40°C to +85°C
Item Symbol Min. Typ. Max. Unit Test Conditions
Differential input sensitivity V
DI
0.2 — — V (DP) – (DM)
Differential common mode range V
CM
0.8 — 2.5 V
Single ended receiver threshold
voltage
V
SE
0.8 — 2.0 V
Output high voltage V
OH
2.8 — V
CC
Q V
Output low voltage V
OL
— — 0.3 V
Tri-state leak current I
LO
−10 — 10 µA 0 V < V
IN
< 3.3 V
Note: * The DP and DM pins
Table 25.4 Permissible Output Currents
Conditions: V
CC
= 1.8 V ± 5%, V
CC
Q = 3.0 V to 3.6 V, AV
CC
= 3.0 V to 3.6 V, V
ref
= PLLV
SS
=
AV
SS
= 0 V, Ta = −40°C to +85°C
Item Symbol Min. Typ. Max. Unit
SCL, SDA 10
PE0 to PE4, PE6 15
Permissible output low
current (per pin)
Other than above
I
OL
2
mA
Permissible output low current (total) ΣI
OL
120 mA
Permissible output high current (per pin) −I
OH
2 mA
Permissible output high current (total) Σ−I
OH
40 mA
Caution: To protect the LSI's reliability, do not exceed the output current values in table 25.4.
