Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 867 of 982
REJ09B0023-0400
Register Name Abbreviation Bit No. Address Module Access States
Interrupt mask register 0 IMR0 8 H'A408 0040 INTC 8
Interrupt mask register 1 IMR1 8 H'A408 0042 8
Interrupt mask register 2 IMR2 8 H'A408 0044 8
Interrupt mask register 4 IMR4 8 H'A408 0048 8
Interrupt mask register 5 IMR5 8 H'A408 004A 8
Interrupt mask register 6 IMR6 8 H'A408 004C 8
Interrupt mask register 7 IMR7 8 H'A408 004E 8
Interrupt mask register 8 IMR8 8 H'A408 0050 8
Interrupt mask register 9 IMR9 8 H'A408 0052 8
Interrupt mask register 10 IMR10 8 H'A408 0054 8
Interrupt mask clear register 0 IMCR0 8 H'A408 0060 8
Interrupt mask clear register 1 IMCR1 8 H'A408 0062 8
Interrupt mask clear register 2 IMCR2 8 H'A408 0064 8
Interrupt mask clear register 4 IMCR4 8 H'A408 0068 8
Interrupt mask clear register 5 IMCR5 8 H'A408 006A 8
Interrupt mask clear register 6 IMCR6 8 H'A408 006C 8
Interrupt mask clear register 7 IMCR7 8 H'A408 006E 8
Interrupt mask clear register 8 IMCR8 8 H'A408 0070 8
Interrupt mask clear register 9 IMCR9 8 H'A408 0072 8
Interrupt mask clear register 10 IMCR10 8 H'A408 0074 8
Interrupt request register 0 IRR0 8 H'A414 0004 8
Interrupt control register 1 ICR1 16 H'A414 0010 16
Interrupt control register 3 ICR3 16 H'A414 0020 16
Interrupt priority registers C IPRC 16 H'A414 0016 16
Interrupt priority registers D IPRD 16 H'A414 0018 16
Interrupt priority registers E IPRE 16 H'A414 001A 16
Interrupt priority registers J IPRJ 16 H'A414 0030 16
Interrupt control register 0 ICR0 16 H'A414 FEE0 16
Interrupt priority registers B IPRB 16 H'A414 FEE4 16
— — — —
