Section 16 I
2
C Bus Interface 2 (IIC2)
Rev. 4.00 Sep. 14, 2005 Page 486 of 982
REJ09B0023-0400
Bit Bit Name
Initial
Value R/W Description
1 AAS 0 R/W Slave Address Recognition Flag
In slave receive mode, this flag is set to 1 if the first
frame following a start condition matches bits SVA6 to
SVA0 in SAR.
[Setting conditions]
When the slave address is detected in slave receive
mode
When the general call address is detected in slave
receive mode.
[Clearing condition]
When 0 is written in AAS after reading AAS=1
0 ADZ 0 R/W General Call Address Recognition Flag
This bit is valid in I
2
C bus format slave receive mode.
[Setting condition]
When the general call address is detected in slave
receive mode
[Clearing condition]
When 0 is written in ADZ after reading ADZ=1
16.3.6 Slave Address Register (SAR)
SAR is an 8-bit readable/writable register that selects the communications format and sets the
slave address. In slave mode with the I
2
C bus format, if the upper seven bits of SAR match the
upper seven bits of the first frame received after a start condition, this module operates as the slave
device. SAR is initialized to H'00 by a power-on reset.
Bit Bit Name
Initial
Value R/W Description
7 to 1 SVA6 to SVA0 All 0 R/W Slave Address 6 to 0
These bits set a unique address in bits SVA6 to SVA0,
differing form the addresses of other slave devices
connected to the I
2
C bus.
0 FS 0 R/W Format Select
0: I
2
C bus format is selected
1: Clocked synchronous serial format is selected
