Section 10 Interrupt Controller (INTC)
Rev. 4.00 Sep. 14, 2005 Page 224 of 982
REJ09B0023-0400
Table 10.2 Interrupt Sources and IPRB to IPRJ
Register Bits 15 to 12 Bits 11 to 8 Bits 7 to 4 Bits 3 to 0
IPRB WDT Reserved* Reserved* Reserved*
IPRC IRQ3 IRQ2 IRQ1 IRQ0
IPRD IRQ7 IRQ6 IRQ5 IRQ4
IPRE Reserved* SCIF0 SCIF1 ADC0
IPRF ADC1 SCIF2 USB CMT
IPRG MTU0 (A/B/C/D) MTU0 (V) MTU1 (A/B) MTU1 (V/U)
IPRH MTU2 (A/B) MTU2 (V/U) MTU3 (A/B/C/D) MTU3 (V)
IPRI MTU4 (A/B/C/D) MTU4 (V) POE IIC2
IPRJ DMAC0 DMAC1 DMAC2 DMAC3
Note: * Reserved: These bits are always read as 0. The write value should always be 0.
As shown in table 10.2, on-chip peripheral module or IRQ interrupts are assigned to four 4-bit
groups in each register. These 4-bit groups (bits 15 to 12, bits 11 to 8, bits 7 to 4, and bits 3 to 0)
are set with values from H'0 (0000) to H'F (1111). Setting of H'0 means priority level 0 (masking
is requested); H'F means priority level 15 (the highest level).
