Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 895 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
PFDR PF15DT PF14DT PF13DT PF12DT PF11DT PF10DT PF9DT PF8DT PORT
PF7DT PF6DT PF5DT PF4DT PF3DT PF2DT PF1DT PF0DT
PGDR — — PG13DT PG12DT PG11DT PG10DT PG9DT PG8DT
PG7DT PG6DT PG5DT PG4DT PG3DT PG2DT PG1DT PG0DT
PHDR — PH14DT PH13DT PH12DT PH11DT PH10DT PH9DT PH8DT
PH7DT PH6DT PH5DT PH4DT PH3DT PH2DT PH1DT PH0DT
PJDR — — — PJ12DT PJ11DT PJ10DT PJ9DT PJ8DT
PJ7DT PJ6DT PJ5DT PJ4DT PJ3DT PJ2DT PJ1DT PJ0DT
Notes: 1. When the following memory is in use: normal memory, byte-selection SRAM, or MPX-
IO (address/data multiplexed I/O)
2. When burst ROM (asynchronous) is in use
3. When burst ROM (synchronous) is in use
4. When SDRAM is in use
5. When burst MPX-IO is in use
