Section 15 User Debugging Interface (H-UDI)
Rev. 4.00 Sep. 14, 2005 Page 458 of 982
REJ09B0023-0400
Table 15.2 H-UDI Commands
Bits 15 to 8
TI7 TI6 TI5 TI4 TI3 TI2 TI1 TI0 Description
0 0 0 0 — — — — JTAG EXTEST
0 0 1 0 — — — — JTAG CLAMP
0 0 1 1 — — — — JTAG HIGHZ
0 1 0 0 — — — — JTAG SAMPLE/PRELOAD
0 1 1 0 — — — — H-UDI reset negate
0 1 1 1 — — — — H-UDI reset assert
1 0 1 — — — — — H-UDI interrupt
1 1 1 0 — — — — JTAG IDCODE (Initial value)
1 1 1 1 — — — — JTAG BYPASS
Other than the above Reserved
15.3.3 Boundary Scan Register (SDBSR)
SDBSR is a 469-bit shift register, located on the PAD, for controlling the input/output pins of this
LSI.
Using the EXTEST, SAMPLE/PRELOAD, CLAMP, and HIGHZ commands, a boundary scan
test conforming to the JTAG standard can be carried out. Table 15.3 shows the correspondence
between this LSI's pins and boundary scan register bits.
