Section 10 Interrupt Controller (INTC)
Rev. 4.00 Sep. 14, 2005 Page 237 of 982
REJ09B0023-0400
Interrupt Source
Exception
Code
Interrupt Priory
(Initial Value)
IPR
(Bit Number)
Priority
within IPR
Setting Unit
Default
Priority
MTU0 TGI0A H'A80 0 to 15 (0) IPRG (15 to 12) High High
TGI0B H'AA0
TGI0C H'AC0
TGI0D H'AE0 Low
TCI0V H'B00 IPRG (11 to 8)
MTU1 TGI1A H'C00 0 to 15 (0) IPRG (7 to 4) High
TGI1B H'C20 Low
TCI1V H'C40 IPRG (3 to 0) High
TCI1U H'C60 Low
MTU2 TGI2A H'C80 0 to 15 (0) IPRH (15 to 12) High
TGI2B H'CA0 Low
TCI2V H'CC0 IPRH (11 to 8) High
TCI2U H'CE0 Low
MTU3 TGI3A H'D00 0 to 15 (0) IPRH (7 to 4) High
TGI3B H'D20
TGI3C H'D40
TGI3D H'D60 Low
TCI3V H'D80 IPRH (3 to 0)
MTU4 TGI4A H'E00 0 to 15 (0) IPRI (15 to 12) High
TGI4B H'E20
TGI4C H'E40
TGI4D H'E60 Low
TCI4V H'E80 IPRI (11 to 8)
CMT CMI0 H'F00 0 to 15 (0) IPRF (3 to 0) High
CMI1 H'F20 Low
SCIF2 ERI2 H'400 0 to 15 (0) IPRF (11 to 8) High
RxI2 H'420
BRI2 H'440
TxI2 H'460 Low
POE OEI H'480 0 to 15 (0) IPRI (7 to 4)
IIC2 IIC2I H'F40 0 to 15 (0) IPRI (3 to 0)
WDT ITI H'560 0 to 15 (0) IPRB (15 to 12) Low
