Section 6 Power-Down Modes
Rev. 4.00 Sep. 14, 2005 Page 168 of 982
REJ09B0023-0400
Bit Bit Name
Initial
Value R/W Description
2 MSTP5 0 R/W Module Stop 5
When the MSTP5 bit is set to 1, the supply of the
clock to the cache memory is halted.
0: The cache memory runs.
1: Clock supply to the cache memory halted.
1 MSTP4 0 R/W Module Stop 4
When the MSTP4 bit is set to 1, the supply of the
clock to the U memory is halted.
0: The U memory runs.
1: Clock supply to the U memory halted.
0 MSTP3 0 R/W Module Stop 3
When the MSTP3 bit is set to 1, the supply of the
clock to the X/Y memory is halted.
0: The X/Y memory runs.
1: Clock supply to the X/Y memory halted.
6.2.3 Standby Control Register 3 (STBCR3)
STBCR3 is a readable/writable 8-bit register used to select whether or not individual modules
operate in power-down mode. STBCR3 is initialized (to H'00) by a power-on reset, but retains its
previous value after a manual reset or a period in the standby mode. Only byte access is valid.
Bit Bit Name
Initial
Value R/W Description
7 HIZ 0 R/W Port High Impedance
This bit selects whether the state of a specified pin is
retained or the pin is placed in the high-impedance
state. See Appendix A, Pin States to determine the
pin to which this control is applied.
Do not set this bit when the TME bit of WTSCR of the
WDT is 1. When setting the output pin to the high-
impedance state, set the HIZ bit with the TME bit
being 0.
0: The pin state is held in standby mode.
1: The pin state is set to the high-impedance state in
standby mode.
