Section 10 Interrupt Controller (INTC)
Rev. 4.00 Sep. 14, 2005 Page 236 of 982
REJ09B0023-0400
Table 10.5 Interrupt Exception Handling Sources and Priority
Interrupt Source
Exception
Code
Interrupt Priory
(Initial Value)
IPR
(Bit Number)
Priority
within IPR
Setting Unit
Default
Priority
NMI H'1C0 16 High
H-UDI interrupt H'5E0 15
IRQ IRQ0 H'600 0 to 15 (0) IPRC (3 to 0)
IRQ1 H'620 0 to 15 (0) IPRC (7 to 4)
IRQ2 H'640 0 to 15 (0) IPRC (11 to 8)
IRQ3 H'660 0 to 15 (0) IPRC (15 to 12)
IRQ4 H'680 0 to 15 (0) IPRD (3 to 0)
IRQ5 H'6A0 0 to 15 (0) IPRD (7 to 4)
IRQ6 H'6C0 0 to 15 (0) IPRD (11 to 8)
IRQ7 H'6E0 0 to 15 (0) IPRD (15 to 12)
DMAC0 DEI0 H'800 0 to 15 (0) IPRJ (15 to 12)
DMAC1 DEI1 H'820 0 to 15 (0) IPRJ (11 to 8)
DMAC2 DEI2 H'840 0 to 15 (0) IPRJ (7 to 4)
DMAC3 DEI3 H'860 0 to 15 (0) IPRJ (3 to 0)
SCIF0 ERI0 H'880 0 to 15 (0) IPRE (11 to 8) High
RxI0 H'8A0
BRI0 H'8C0
TxI0 H'8E0 Low
SCIF1 ERI1 H'900 0 to 15 (0) IPRE (7 to 4) High
RxI1 H'920
BRI1 H'940
TxI1 H'960 Low
ADC ADI0 H'980 0 to 15 (0) IPRE (3 to 0) High
ADI1 H'9A0 IPRF (15 to 12) Low
USB USI0 H'A00 0 to 15 (0) IPRF (7 to 4) High
USI1 H'A20
USIHP H'A40 Low Low
