Section 22 Pin Function Controller (PFC)
Rev. 4.00 Sep. 14, 2005 Page 823 of 982
REJ09B0023-0400
Port Port Function (Related Module) Other Function (Related Module)
J PTJ12 input/output (port) AUDSYNC output (AUD)
PTJ11 input/output (port) AUDATA3 output (AUD)
PTJ10 input/output (port) AUDATA2 output (AUD)
PTJ9 input/output (port) AUDATA1 output (AUD)
PTJ8 input/output (port) AUDATA0 output (AUD)
PTJ7 input/output (port) IRQ7 input (INTC)
PTJ6 input/output (port) IRQ6 input (INTC)
PTJ5 input/output (port) IRQ5 input (INTC)
PTJ4 input/output (port) IRQ4 input (INTC)
PTJ3 input/output (port) IRQ3 input (INTC)
PTJ2 input/output (port) IRQ2 input (INTC)
PTJ1 input/output (port) IRQ1 input (INTC)
PTJ0 input/output (port) IRQ0 input (INTC)
22.1 Register Descriptions
The registers of the pin function controller are shown below.
• Port A control register (PACR)
• Port B control register (PBCR)
• Port C control register (PCCR)
• Port D control register (PDCR)
• Port E control register (PECR)
• Port E I/O register (PEIOR)
• Port E MTU R/W enable register (PEMTURWER)
• Port F control register (PFCR)
• Port G control register (PGCR)
• Port H control register (PHCR)
• Port J control register (PJCR)
