Section 18 Multi-Function Timer Pulse Unit (MTU)
Rev. 4.00 Sep. 14, 2005 Page 617 of 982
REJ09B0023-0400
Table 18.42 MTU Interrupts
Channel
Name
Interrupt Source
Interrupt
Flag
DMA
Activation
Priority
0 TGI0A TGRA_0 input capture/compare match TGFA_0 Possible High
TGI0B TGRB_0 input capture/compare match TGFB_0 Not possible
TGI0C TGRC_0 input capture/compare match TGFC_0 Not possible
TGI0D TGRD_0 input capture/compare match TGFD_0 Not possible
TCI0V TCNT_0 overflow TCFV_0 Not possible
1 TGI1A TGRA_1 input capture/compare match TGFA_1 Possible
TGI1B TGRB_1 input capture/compare match TGFB_1 Not possible
TCI1V TCNT_1 overflow TCFV_1 Not possible
TCI1U TCNT_1 underflow TCFU_1 Not possible
2 TGI2A TGRA_2 input capture/compare match TGFA_2 Possible
TGI2B TGRB_2 input capture/compare match TGFB_2 Not possible
TCI2V TCNT_2 overflow TCFV_2 Not possible
TCI2U TCNT_2 underflow TCFU_2 Not possible
3 TGI3A TGRA_3 input capture/compare match TGFA_3 Possible
TGI3B TGRB_3 input capture/compare match TGFB_3 Not possible
TGI3C TGRC_3 input capture/compare match TGFC_3 Not possible
TGI3D TGRD_3 input capture/compare match TGFD_3 Not possible
TCI3V TCNT_3 overflow TCFV_3 Not possible
4 TGI4A TGRA_4 input capture/compare match TGFA_4 Possible
TGI4B TGRB_4 input capture/compare match TGFB_4 Not possible
TGI4C TGRC_4 input capture/compare match TGFC_4 Not possible
TGI4D TGRD_4 input capture/compare match TGFD_4 Not possible
TCI4V TCNT_4 overflow/underflow TCFV_4 Not possible Low
Note: This table shows the initial state immediately after a reset. The relative channel priority can
be changed by the interrupt controller.
Input Capture/Compare Match Interrupt: An interrupt is requested if the TGIE bit in TIER is
set to 1 when the TGF flag in TSR is set to 1 by the occurrence of a TGR input capture/compare
match on a particular channel. The interrupt request is cleared by clearing the TGF flag to 0. The
MTU has 16 input capture/compare match interrupts, four each for channels 0, 3, and 4, and two
each for channels 1 and 2.
