Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 898 of 982
REJ09B0023-0400
Register
Abbreviation Power-On Reset Manual Reset
Software
Standby Module Standby Sleep Module
BBRA Initialized Retained Retained Retained Retained UBC
BRDR Undefined*
2
Retained Retained Retained Retained
CMNCR Initialized Retained Retained Retained BSC
CS0BCR Initialized Retained Retained Retained
CS2BCR Initialized Retained Retained Retained
CS3BCR Initialized Retained Retained Retained
CS4BCR Initialized Retained Retained Retained
CS5ABCR Initialized Retained Retained Retained
CS5BBCR Initialized Retained Retained Retained
CS6ABCR Initialized Retained Retained Retained
CS6BBCR Initialized Retained Retained Retained
CS0WCR Initialized Retained Retained Retained
CS2WCR Initialized Retained Retained Retained
CS3WCR Initialized Retained Retained Retained
CS4WCR Initialized Retained Retained Retained
CS5AWCR Initialized Retained Retained Retained
CS5BWCR Initialized Retained Retained Retained
CS6AWCR Initialized Retained Retained Retained
CS6BWCR Initialized Retained Retained Retained
SDCR Initialized Retained Retained Retained
RTCSR Initialized Retained Retained Retained
RTCNT Initialized Retained Retained Retained
RTCOR Initialized Retained Retained Retained
RWTCNT Initialized Retained Retained Retained
SAR_0 Undefined Undefined Retained Retained Retained DMAC
DAR_0 Undefined Undefined Retained Retained Retained
DMATCR_0 Undefined Undefined Retained Retained Retained
CHCR_0 Initialized Initialized Retained Retained Retained
SAR_1 Undefined Undefined Retained Retained Retained
