Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 902 of 982
REJ09B0023-0400
Register
Abbreviation Power-On Reset Manual Reset
Software
Standby Module Standby Sleep Module
TIER_2 Initialized Retained Initialized Initialized Retained MTU
TSR_2 Initialized Retained Initialized Initialized Retained
TCNT_2 Initialized Retained Initialized Initialized Retained
TGRA_2 Initialized Retained Initialized Initialized Retained
TGRB_2 Initialized Retained Initialized Initialized Retained
ICSR1 Initialized Retained Retained Retained Retained
OCSR Initialized Retained Retained Retained Retained
SCSMR_0 Initialized Retained Retained Retained Retained SCIF
SCBRR_0 Initialized Retained Retained Retained Retained
SCSCR_0 Initialized Retained Retained Retained Retained
SCFTDR_0 Undefined Retained Retained Retained Retained
SCFSR_0 Initialized Retained Retained Retained Retained
SCFRDR_0 Undefined Retained Retained Retained Retained
SCFCR_0 Initialized Retained Retained Retained Retained
SCFDR_0 Initialized Retained Retained Retained Retained
SCSPTR_0 Initialized Retained Retained Retained Retained
SCLSR_0 Initialized Retained Retained Retained Retained
SCSMR_1 Initialized Retained Retained Retained Retained
SCBRR_1 Initialized Retained Retained Retained Retained
SCSCR_1 Initialized Retained Retained Retained Retained
SCFTDR_1 Undefined Retained Retained Retained Retained
SCFSR_1 Initialized Retained Retained Retained Retained
SCFRDR_1 Undefined Retained Retained Retained Retained
SCFCR_1 Initialized Retained Retained Retained Retained
SCFDR_1 Initialized Retained Retained Retained Retained
SCSPTR_1 Initialized Retained Retained Retained Retained
SCLSR_1 Initialized Retained Retained Retained Retained
SCSMR_2 Initialized Retained Retained Retained Retained
SCBRR_2 Initialized Retained Retained Retained Retained
