2.4.3 CPU Instruction Formats
Table 2.13 shows the instruction formats, and the meaning of the source and destination operands,
for instructions executed by the CPU core. The meaning of the operands depends on the
instruction code. The following symbols are used in the table.
xxxx: Instruction code
mmmm: Source register
nnnn: Destination register
iiii: Immediate data
dddd: Displacement
Table 2.13 CPU Instruction Formats
Instruction Format
Source
Operand
Destination
Operand Sample Instruction
0 type
xxxx xxxx xxxxxxxx
15 0
NOP
n type
xxxx xxxx xxxxnnnn
15 0
nnnn: register
direct
MOV T Rn
Control register or
system register
nnnn: register
direct
STS MACH,Rn
Control register or
system register
nnnn: pre-
decrement register
indirect
STC.L SR,@-Rn
m type
xxxx
mmmmxxxx xxxx
15 0
mmmm: register
direct
Control register or
system register
LDC Rm,SR
mmmm: post-
increment register
indirect
Control register or
system register
LDC.L @Rm+,SR
mmmm: register
indirect
JMP @Rm
PC-relative using
Rm
BRAF Rm
