Section 24 List of Registers
Rev. 4.00 Sep. 14, 2005 Page 879 of 982
REJ09B0023-0400
Register
Abbreviation
Bit
31/23/15/7
Bit
30/22/14/6
Bit
29/21/13/5
Bit
28/20/12/4
Bit
27/19/11/3
Bit
26/18/10/2
Bit
25/17/9/1
Bit
24/16/8/0 Module
BETR — — — — BET11 BET10 BET9 BET8 UBC
BET7 BET6 BET5 BET4 BET3 BET2 BET1 BET0
BARB BAB31 BAB30 BAB29 BAB28 BAB27 BAB26 BAB25 BAB24
BAB23 BAB22 BAB21 BAB20 BAB19 BAB18 BAB17 BAB16
BAB15 BAB14 BAB13 BAB12 BAB11 BAB10 BAB9 BAB8
BAB7 BAB6 BAB5 BAB4 BAB3 BAB2 BAB1 BAB0
BAMRB BAMB31 BAMB30 BAMB29 BAMB28 BAMB27 BAMB26 BAMB25 BAMB24
BAMB23 BAMB22 BAMB21 BAMB20 BAMB19 BAMB18 BAMB17 BAMB16
BAMB15 BAMB14 BAMB13 BAMB12 BAMB11 BAMB10 BAMB9 BAMB8
BAMB7 BAMB6 BAMB5 BAMB4 BAMB3 BAMB2 BAMB1 BAMB0
BBRB — — — — — — XYE XYS
CDB1 CDB0 IDB1 IDB0 RWB1 RWB0 SZB1 SZB0
BRSR SVF BSA27 BSA26 BSA25 BSA24
BSA23 BSA22 BSA21 BSA20 BSA19 BSA18 BSA17 BSA16
BSA15 BSA14 BSA13 BSA12 BSA11 BSA10 BSA9 BSA8
BSA7 BSA6 BSA5 BSA4 BSA3 BSA2 BSA1 BSA0
BARA BAA31 BAA30 BAA29 BAA28 BAA27 BAA26 BAA25 BAA24
BAA23 BAA22 BAA21 BAA20 BAA19 BAA18 BAA17 BAA16
BAA15 BAA14 BAA13 BAA12 BAA11 BAA10 BAA9 BAA8
BAA7 BAA6 BAA5 BAA4 BAA3 BAA2 BAA1 BAA0
BAMRA BAMA31 BAMA30 BAMA29 BAMA28 BAMA27 BAMA26 BAMA25 BAMA24
BAMA23 BAMA22 BAMA21 BAMA20 BAMA19 BAMA18 BAMA17 BAMA16
BAMA15 BAMA14 BAMA13 BAMA12 BAMA11 BAMA10 BAMA9 BAMA8
BAMA7 BAMA6 BAMA5 BAMA4 BAMA3 BAMA2 BAMA1 BAMA0
BBRA — — — — — — — —
CDA1 CDA0 IDA1 IDA0 RWA1 RWA0 SZA1 SZA0
BRDR DVF BDA27 BDA26 BDA25 BDA24
BDA23 BDA22 BDA21 BDA20 BDA19 BDA18 BDA17 BDA16
BDA15 BDA14 BDA13 BDA12 BDA11 BDA10 BDA9 BDA8
BDA7 BDA6 BDA5 BDA4 BDA3 BDA2 BDA1 BDA0
